Uflow 5/2 Double Solenoid Directional Control Poppet Valve

Description
Features

Uflow 5/2 Double Solenoid Directional Control Poppet Valve – Precision Pneumatic Control

Description:
The Uflow 5/2 Double Solenoid Directional Control Poppet Valve is a highly efficient, bistable valve designed for controlling the flow of compressed air in pneumatic systems. With a robust internal pilot-operated poppet design, this directional control valve offers precise and reliable switching between two flow paths, ideal for a wide range of industrial applications. The valve operates effectively in environments with filtered and lubricated compressed air, ensuring smooth and consistent performance in automation processes.

Key Specifications:

Valve Size: 1/4 inch
Port Sizes: Inlet, Outlet, and Exhaust – 1/4 inch
Orifice Diameter: 7 mm
Media Compatibility: Filtered & Lubricated Compressed Air
Ambient Temperature Range: 5°C to 60°C
Materials: Aluminium, Nitrile Rubber, Brass, Polymer
Voltage Range:
- AC Versions: 24V, 110V, 230V (9W each)
- DC Versions: 12V DC, 24V DC
Power Consumption:
- AC: 9W each
- DC: 10W for 12V DC, 11W for 24V DC
Flow Factor: 18 kv (Flow capacity equivalent to liters of water at a 1 bar pressure difference)

Applications:

Pneumatic automation systems
Industrial machinery control
Compressed air flow regulation
Air filtration and regulation systems

The Uflow 5/2 Double Solenoid Directional Control Poppet Valve provides superior performance, flexibility, and durability in demanding pneumatic environments. Whether you require a valve for industrial air control, pneumatic systems, or specialized automation, this valve ensures precision and reliability across a wide range of applications.

High reliability and resistance to voltage surges
Lockable in four positions at 90-degree increments or free movement between positions
Available in multiple enclosures, offering flexibility for various applications:
- IP65: Dust-tight and water-resistant
- IP67: Protected against immersion
- IP68: Suitable for continuous immersion in water
- Flameproof junction box available for hazardous environments
High Durability: Constructed with high-quality aluminium, nitrile rubber, and brass for long-lasting performance in demanding environments.
Precision Control: Designed for accurate switching and control in pneumatic systems with a 7 mm orifice diameter.
Multiple Voltage Options: Available in AC and DC voltages (24V, 110V, 230V AC & 12V, 24V DC) to suit a variety of system requirements.
Energy Efficient: Power consumption is optimized with a power-saving circuit, making it cost-effective for continuous use.
Flexible Enclosure Options: IP65, IP67, and IP68 enclosures offer varying levels of protection for diverse industrial applications.
Compact & Reliable: Offers easy integration into automation systems with a compact design and high resistance to voltage surges.
